Pressol P13 Locking Grease Coupler – 12,000 PSI, Slim 13 mm Design with 360° Swivel
Pressol P13 Locking Grease Coupler – 12,000 PSI, Slim 13 mm Design with 360° Swivel
Key Features
- Professional locking grease coupler rated up to 12,000 PSI
- Slim 13 mm—0.51-inch—outside diameter
- Reaches recessed fittings and confined lubrication points
- Six hardened clamping jaws provide a strong, balanced grip
- Locks securely onto standard grease fittings
- Hands-free connection allows easier grease-gun operation
- Smooth-operating comfort lever supports easy installation and removal
- Included 360-degree swivel reduces hose twisting and binding
- Standard 1/8-inch NPT connection for U.S. grease-gun compatibility
- Helps reduce grease leakage, wasted lubricant, and messy connections
- Compatible with manual, pneumatic, and battery-powered grease guns
- German-engineered for professional lubrication applications
The Pressol P13 is a professional locking grease coupler engineered to provide secure, hands-free connections without the bulky profile of conventional locking couplers.
About this Item:
Reliable. Tight. Slim.
The Pressol P13 is a professional locking grease coupler engineered to provide secure, hands-free connections without the bulky profile of conventional locking couplers.
Measuring only 13 mm—or approximately 0.51 inches—in diameter, the P13 reaches recessed and tightly spaced grease fittings that larger locking couplers may not be able to access. Six hardened clamping jaws create a secure, evenly distributed grip around the grease fitting, helping prevent accidental disconnection and grease leakage during high-pressure lubrication.
Rated for pressures up to 12,000 PSI, the P13 is built for manual, pneumatic, and battery-powered grease guns. Its smooth-operating comfort lever makes the coupler easy to connect, securely lock, and release after lubrication.
An included 360-degree swivel fitting allows the hose and grease gun to move freely without twisting or placing unnecessary strain on the fitting. Whether servicing vehicles, farm machinery, construction equipment, or industrial machinery, the P13 provides secure access and professional high-pressure performance.
Specifications
| Specification | U.S. Value |
|---|---|
| Product | P13 locking grease coupler |
| Maximum pressure rating | 12,000 PSI |
| Inlet connection | 1/8 in.-27 NPT |
| Outside diameter | 0.51 in. |
| Metric outside diameter | 13 mm |
| Locking mechanism | Lever operated |
| Number of clamping jaws | Six |
| Swivel | 360° swivel included |
| Fitting compatibility | Standard hydraulic grease fittings |
| Grease-gun compatibility | Manual, pneumatic and battery-powered |
| Operation | Lock-on, hands-free lubrication |
Slim Access for Tight Spaces
Many locking grease couplers are too large to reach fittings located inside recessed openings or between closely spaced components. With its narrow 13 mm profile, the Pressol P13 delivers the convenience of a locking coupler without sacrificing access.
This makes it especially useful around driveshafts, universal joints, steering components, agricultural equipment, construction machinery, and tightly packaged industrial assemblies.
Six-Jaw Locking System
Instead of relying on four contact points, the P13 uses six hardened clamping jaws to grip the grease fitting. The six-jaw configuration distributes holding force more evenly around the fitting, producing a secure connection during demanding high-pressure lubrication.
Once connected, the P13 remains attached without being held in place, leaving both hands available to operate the grease gun or stabilize the hose.
Included 360-Degree Swivel
The integrated 360-degree swivel allows the grease hose to rotate freely as the operator changes position. This reduces twisting, improves access, and helps prevent the hose from pulling the coupler sideways during lubrication.
Built for High-Pressure Greasing
With a maximum pressure rating of 12,000 PSI, the P13 is suitable for demanding professional lubrication work and modern high-pressure battery grease guns. Its secure locking action helps maintain the connection when servicing stubborn or restricted grease fittings.
